Military Land Vehicles
In military land vehicles, reliable performance is not an option, it's a must.
With its aerospace pedigree, Aero-Hose, Corp.'s products undergo rigorous testing and quality verifications.
With decades of experience and hundreds of thousands of assemblies manufactured, Aero-Hose, Corp. is the ideal partner for critical applications. From standard fuel and hydraulic lines to complex hose/tube combinations used in turret systems, Aero-Hose, Corp.'s products are found in military land vehicles throughout the world.
Whether the vehicle is used for troop, fuel and supply transport or combat, when choosing Aero-Hose, Corp., quality, service and performance are never a question.
R160 (240 SERIES)
The 240 Series is a lightweight high pressure 3000 PSI (207 Bar) aerospace hose qualified to AS1339. The hose consists of an extruded smoothbore PTFE inner core, reinforced with CRES 304 wire braid in a single layer on sizes -04 through -10, or a double layer on sizes -12 through -24. The PTFE inner core is conductive and provides excellent chemical resistance through a temperature range of -65°F to +400°F (-54°C to +204°C) with unlimited shelf life.
The pre-tensioned braid gives 240 Series hose the tightest bend radius of any metal braided high pressure PTFE hose.
The standard fitting material is CRES, but titanium is also available for weight savings. Fire protection per AS1055 Class A & B can be either integral or slip-on AS1072 firesleeve.
Chafe sleeves are available in a variety of integral or slip-on materials.
Hybrid assemblies combining flex hose with multi-bend tube are a Titeflex specialty and provide improved vibration dampening, ease of installation and maintenance over strictly rigid tube from sizes -16 to -24: less than AS1339 rating.
Featured Product
Series
240
Specification
SAE AS1339
Braid
CRES
Innercore
PTFE Smoothbore
Qualification
SAE AS1339
TSO C75 Type IIIB-S/P-F
AS1055 Type IIa & IIb, Class A & B,
Integral and Slip-on Firesleeve
Full Catalog
Aero-Hose, Corp. offers a broad range of products for Commercial applications.
