R160 (240 Series) Hose Assembly

R160 (240 Series) Hose Assembly

The 240 Series is a lightweight high pressure 3000 PSI (207 Bar) aerospace hose qualified to AS1339. The hose consists of an extruded smoothbore PTFE innercore, reinforced with CRES 304 wire braid in a single layer on sizes -04 through -10, or a double layer on sizes -12 through -24.

Additional information
Series

240

Specification

SAE AS1339

Braid

CRES

Innercore

PTFE Smoothbore

Qualifications

SAE AS1339, TSO C75 Type IIIB-S/P-F, AS1055 Type IIa & IIb, Class A & B, Integral and Slip-on Firesleeve

Description

R160 (240 Series)
The 240 Series is a lightweight high pressure 3000 PSI (207 Bar) aerospace hose qualified to AS1339. The hose consists of an extruded smoothbore PTFE innercore, reinforced with CRES 304 wire braid in a single layer on sizes -04 through -10, or a double layer on sizes -12 through -24. The PTFE innercore is conductive and provides excellent chemical resistance through a temperaturerange of -65°F to +400°F (-54°C to +204°C) with unlimited shelf life. The pre-tensioned braid gives 240 Series hose the tightest bend radius of any metal braided high pressure PTFE hose. The standard fitting material is CRES, but titanium is also available for weight savings. Fire protection per AS1055 Class A & B can be either integral or slip-on AS1072 firesleeve. Chafe sleeves are available in a variety of integral or slip-on materials. Hybrid assemblies combining flex hose with multi-bend tube are a Titeflex specialty and provide improved vibration dampening, ease of installation and maintenance over strictly rigid tube from sizes -16 to -24: less than AS1339 rating.

Attachments

R367 (480 series)

R367 (480 series) is a medium pressure aerospace hose assembly qualified to AS620. It consists of a helically convoluted (tape wrap) PTFE innercore, reinforced with a CRES 304 wire braid. The convoluted innercore enables the 480 Series to bend to a tighter radius, with less force, than smooth bore PTFE hose of similar diameter.

Product SKU: r367-480series

Product Brand: Titeflex

Price Valid Until: 2023-01-01

Product In-Stock: InStock

Editor's Rating:
4.7

Additional information

Series

240

Specification

SAE AS1339

Braid

CRES

Innercore

PTFE Smoothbore

Qualifications

SAE AS1339, TSO C75 Type IIIB-S/P-F, AS1055 Type IIa & IIb, Class A & B, Integral and Slip-on Firesleeve
